NHTSA ID Number: 10161810
Manufacturer Communication Number: TJ3485010-2019-0
Summary
This is a Technical Journal: DIM message, ‘Climate System – Internal Cooling”. Verify with the customer that the message they have seen matches the image in attachment
1 Affected Product
Vehicle
MAKE | MODEL | YEAR |
VOLVO | XC90 | 2018 |
SEOCONTENT-START
VOLVO CAR
SERVICE AND PARTS BUSINESS
Technical Journal
TITLE:
DIM message, “Climate System – Internal Cooling”
REF NO:
TJ 34850.1.0
ISSUING DEPARTMENT:
Technical Service
CAR MARKET:
United States and Canada
PARTNER:
3 US 7510 Volvo Car USA
ISSUE DATE:
2019-05-24
STATUS DATE:
2019-05-30
FUNC GROUP:
3810
FUNC DESC:
Combined instrument Page 1 of 3
Produced in the USA and available as an electronic document. Hard copy documents are printed in USA on recycled paper containing
a minimum of 50% wastepaper and 10% post-consumer waste.
© 2019 VOLVO CAR USA, LLC
“Right first time in Time”
Attachment
File Name File Size
TJ 34850.jpg 0.0369 MB
Vehicle Type
Type Eng Eng
Desc Sales Body Gear Steer Model Year Plant Chassis range Struc Week
Range
2XX 2016-9999 – 201505-999952
536 2018-9999 – 201746-999952
CSC Customer Symptom Codes
Code Description
FB Text window and warning symbol/Other problems
IV Text window and warning symbol/Text message
8M Warning lights and chimes/Other warning/chime problems
VST Operation Number
DTC Diagnostic Trouble Codes
Text
Page 2 of 3 2019-05-30
Technical Journal 34850.1.0
DESCRIPTION:
DIM = Driver Information Module
IHU = Infotainment Head Unit
CCD = Center Console Display
If the customer reports that the message “Climate system running due to internal cooling” has appeared
in the DIM and/or CCD display (see attachment TJ 34850.jpg), this is a normal function of the car, see
text under “Service”.
This may occur if the customer is driving with the climate control system set to “OFF” during warmer
weather conditions (ambient temperature above 68°F/20°C).
SERVICE:
Verify with the customer that the message they have seen matches the image in attachment TJ 34850.jpg.
Please do NOT perform any fault tracing or replace any components due to this message. It is a normal
function and does not indicate a fault with the vehicle:
This message appears due to a function called Active Cooling:
If the climate control system in the vehicle is switched OFF during high ambient temperature conditions,
the blower fan may need to come on periodically to circulate air behind the dashboard in order to cool
down electronic components such as the IHU, DIM, or CCD, when needed.
In some conditions, the blower fan alone may be inadequate to cool the electronics and the Air
Conditioning may become active for a short time as well.
This message will appear in the DIM and/or CCD displays to inform the customer when this system is
operating. The customer should be advised that this is normal operation.
VEHICLE REPORT:
Yes, please submit a Vehicle Report if the service solution described in this TJ has no effect. Use
concern area “Vehicle Report” and sub concern area “Support not needed”, use function group 3810.
To view TJ attachment continue to next page. This TJ has one attachment.
2019-05-30 Page 3 of 3
Technical Journal 34850.1.0
SEOCONTENT-END
TJ 34850.1.0
STATUS DATE:
2019-05-30
