NHTSA ID Number: 10161809
Manufacturer Communication Number: TJ3478720-2019-0
Summary
This is a Technical Journal: Ping noise from exhaust when cooling down
24 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| VOLVO | S60 | 2019 |
| VOLVO | S60CC | 2019 |
| VOLVO | S60I | 2019 |
| VOLVO | S90 | 2017 |
| VOLVO | V60 | 2018-2019 |
| VOLVO | V60CC | 2018-2019 |
| VOLVO | V90 | 2017-2019 |
| VOLVO | V90CC | 2017-2019 |
| VOLVO | XC60 | 2018-2019 |
| VOLVO | XC90 | 2016-2019 |
| VOLVO | XC90H | 2016-2019 |
SEOCONTENT-START
VOLVO CAR
SERVICE AND PARTS BUSINESS
Technical Journal
TITLE:
Ping noise from exhaust when cooling down
REF NO:
TJ 34787.2.0
ISSUING DEPARTMENT:
Technical Service
CAR MARKET:
United States and Canada
PARTNER:
3 US 7510 Volvo Car USA
ISSUE DATE:
2019-05-23
STATUS DATE:
2019-05-29
FUNC GROUP:
2520
FUNC DESC:
Silencer and exhaust pipe Page 1 of 2
Produced in the USA and available as an electronic document. Hard copy documents are printed in USA on recycled paper containing
a minimum of 50% wastepaper and 10% post-consumer waste.
© 2019 VOLVO CAR USA, LLC
“Right first time in Time”
Attachment
File Name File Size
Abnormal ping sound.m4a 1.3555 MB
Vehicle Type
Type Eng Eng
Desc Sales Body Gear Steer Model Year Plant Chassis range Struc Week
Range
224 2019-2099 – 201835-209952
224 2019-2099 – 201846-209952
225 2019-2099 – 201817-209952
227 2019-2099 – 201846-209952
234 2017-2099 – 201617-209952
235 2017-2099 – 201624-209952
236 2017-2099 – 201646-209952
246 2018-2099 – 201717-209952
256 2016-2099 – 201505-209952
CSC Customer Symptom Codes
Code Description
XB Exhaust system/Rattle/rumble
VST Operation Number
Page 2 of 2 2019-05-29
Technical Journal 34787.2.0
DTC Diagnostic Trouble Codes
Rows beginning with * are modified
Note! If using a printed copy of this Technical Journal, first check for the latest online version.
Text
DESCRIPTION:
This journal is to collect information and case building.
If an abnormal ping sound from the silencer occurs when cooling down. (Listen in attachment after 8
seconds and 35 seconds)
Follow action under “service”
SERVICE:
Do not replace any part! A new silencer is planned 2020Q1.
Yes, please submit a Vehicle Report. Use concern area “Vehicle Report” and sub concern area “Support
not needed”, use function group 2520.
Warranty claim info:
No warranty claim accepted for a job described in this TJ.
VEHICLE REPORT:
Yes, please submit a Vehicle Report for case building. Use concern area “Vehicle Report” and sub
concern area “Support not needed”, use function group 2520.
This Technical Journal has an associated sound file.
SEOCONTENT-END
REF NO:
TJ 34787.2.0
STATUS DATE:
2019-05-29
https://www.nhtsa.gov/recalls?nhtsaId=10161809
https://static.nhtsa.gov/odi/tsbs/2019/MC-10161809-9999.pdf
