December 7, 2023 NHTSA CAMPAIGN NUMBER: 23V827000
Second-Row Seat Belt Buckle Not Tightened Properly
An improperly tightened seat belt buckle may not restrain an occupant as intended, increasing their risk of injury during a crash.
NHTSA Campaign Number: 23V827
Manufacturer Volvo Car USA, LLC
Components SEAT BELTS
Potential Number of Units Affected 2,911
Summary
Volvo Car USA, LLC (Volvo Car) is recalling certain 2015-2024 XC90 vehicles. The second-row seat belt buckle and lower belt anchor bolts may not be tightened properly.
Remedy
Dealers will inspect and tighten the second-row seat belt buckle anchorage bolts, as necessary, free of charge. Owner notification letters are expected to be mailed January 29, 2024. Owners may contact Volvo Car customer service at 1-800-458-1552. Volvo Car’s number for this recall is R10259.
Notes
Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.nhtsa.gov.
Check if your Volvo has a Recall
QB Instruction VCC-528486-2
Safety belt buckle and safety belt tensioner
RECALL R10259 DESCRIPTION
Volvo Cars USA LLC and Volvo Cars Canada LTD on behalf of the Volvo Car Corporation has decided to launch Recall R10259: Seatbelt Buckle on certain model year 2015-2024 XC90 vehicles.
Volvo Car Investigations have determined that the second-row seatbelt buckles, and lower anchorages may have not been torqued to the correct specification.
If the screw joint was not sufficiently tightened, the second-row seatbelt buckle may come loose in a crash, increasing the risk of injury.
To remedy concerned vehicles, Volvo Cars will inspect the bolt torque on the second-row seatbelt buckle anchorage bolts ensuring all bolts are torqued according to specification.
Volvo Cars centrally has not received any reports alleging injuries, fatalities, or crashes related to this condition.
A total of 2,911 U.S. and 233 Canadian vehicles are eligible for this recall.
WHAT SHOULD YOUR CUSTOMERS DO NOW?
We have no reports of incidents related to the issue; however, we encourage customers to contact their retailer and have this repair completed as soon as possible.
OWNER NOTIFICATION
An owner notification will be sent out in late-January that will notify the owner of this recall instructing them to contact their Volvo Retailer and request an appointment to have this repair completed.
Chronology :
Considered as a critical concern by CCMT 2023-11-29; Field Service Action decision confirmed by Volvo Car Corporation 2023-12-06; Condition detected by Factory; Number of vehicles reports with the condition, reported to Volvo Cars from the NSC 0; Total number of cars included in vehicle reports concerning this condition 0; Implementation date of Field Service Action 2023-12-07.
Extended Chronology:
2023-10-04 Volvo cars received the first factory notification indicating second row seat belt buckle was loose at the lower anchor. An investigation was initiated to review the factory symptom and a possible root cause.
2023-11-22 The investigation was escalated to the Critical Concern Action Process (CCAP).
The issue was determined as potentially critical and the Critical Concern Management Team (CCMT) initiated a technical investigation to conclude customer symptom, risk assessment, testing, root cause etc together with the supplier.
On 2023-11-29 the technical investigation was completed, the CCMT team took the decision to start preparation for a recall as it was judged that there is an increased risk towards motor vehicle safety.
10 Affected Products
Vehicle
MAKE | MODEL | YEAR |
VOLVO | XC90 | 2015-2024 |
5 Associated Documents
Recall Acknowledgement
RCAK-23V827-6357.pdf 645.411KB
Remedy Instructions and TSB
RCRIT-23V827-8426.pdf 4013.351KB
Manufacturer Notices(to Dealers,etc)
RCMN-23V827-2952.pdf 116.506KB
Defect Notice 573 Report
RCLRPT-23V827-6050.PDF 215.901KB
Remedy Instructions and TSB
RCRIT-23V827-8436.pdf 559.782KB
Latest Recalls Documents
For the Latest and Most recent Recall Information Visit the link below…
https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=23V827&docType=RCL
- VOL II can do it all-reads and clears trouble codes for Volvo Saab on all the systems such as engine, transmission, ABS and SRS etc. Read & Clear DTCs Read live data stream
- Oil light/service reset, Electronic Parking Brake (EPB) system maintenance, Steering Angle Sensor (SAS) Calibration, Diesel Particulate Filter (DPF) Regeneration Control System, Electronic Throttle Control system (ETC) reset
- OBD II function for all OBD II/EOBD compliant vehicles: I/M Readiness, Data Stream, Freeze Frame, O2 Sensor Test, Turn off Check Engine Light (MIL)…
- Lifetime free update Upgrade Via TF Card one year warranty Support Multi-language
- ALL SYSTEM DIAGNOSTICS FOR VOLVO BRANDS - Foxwell NT530 Car Diagnostic Scan Tool for Volvo is capable of diagnosing all available electronic systems such as ABS, SRS, SAS, Transmission, EPS, Auto Bleed, TPMS, D-P-F, EPB, Oil Reset, HVAC, Keyless Entry, LKAS Control - it helps you diagnose and calibrate your vehicle's faults - no more dealership and SAVE thousands of dollars on your car's maintenance
- ADVANCED MAINTENANCE SERVICE FEATURES - This automotive OBDII scanner works specifically with Volvo and supports body, chassis, powertrain and other control modules check; it also performs coding, resest oil reminder and service lights, deactivates parking brake for brake change, resets throttle position sensor, regenerate d-pf, replace battery, crankshaft sensor relearn, etc
- FULL OBD 10 MODES WITH NO SUBSCRIPTION FEE - This professional auto scanner diagnostic tool can not only do maintenance service resets but can also work on OBDII system - reads and clears codes, turns off MILs, requests and records live sensor data (supports 2 PIDs graphing and numerous live PIDs in text) and freeze frame - full OBDII 10 Modes are not limited to to Volvo vehicles, you can also test it on other brand vehicles, such as on BMW, Mercedes-benz, GM, Porsche, Toyota, etc
- BEST DIYER DIAGNOSTIC TOOL - NT530 scanner works with Volvo brands and is the best scanner for DIYers - bidirectional operation, active test
- NEW HISTORY FEATURE - History feature allows you to save history data and VIN number, no need to input it manually every time
- 🎉【2024 Upgraded Ver. of AL519/ ML519/ ML619】Autel develops the brand-new AutoLink AL619 as the advanced ver. of Autel ML519, AL519, AL319, MS309. This AL619 OBD2 scanner can scan ABS & SRS systems, and support 10 Modes of OBD II Diagnostics Function on Worldwide Vehicles to read, erase codes and turn off the MIL, ABS, SRS warning lights so that you can better maintain your car when related malfunctions occur and make your vehicle ready for the annual test.
- 🎉【Accurate ABS/ SRS Diagnostics Functions】The ABS/ SRS diagnostic function is used to retrieve and clear codes from the ABS/ SRS systems. It can read and clear DTCs, show definitions of each code, display live data of multiple sensors in the graph to locate fault causes, and assist home mechanics to do the proper repair and clear ABS & Airbag warning lights. Diagnoses ABS/ SRS system codes on most 1996 and newer major vehicle models. Please email 📩 immoautel @ outlook. com 📩 for help.
- 🎉【All 10 Modes of OBD II Diagnostics Function】The OBD II Diagnostics function is a fast-access option that allows you to carry out a quick test on the engine system of OBD II vehicles. Read Codes, Erase Codes, Live Data, Freeze Frame, Retrieving I/M Readiness Status, O2 Monitor Test, On-Board Monitor Test, DTC Lookup, Component Test, Viewing Vehicle Information, Modules Present.
- 🎉【Live Data and Freeze Frame Data】With Live Data functions, Autel AL619 OBD2 diagnostic code reader allows you to view the live PID (Parameter Identification Data) of the vehicle's computer module(s) in text, graph to check the status of various sensors. And Freeze Frame Data enables you to view the vehicle's operating parameters at the moment a DTC is detected. These information will aid the technician by allowing the parameters to be duplicated for diagnostic and repair purposes.
- 🎉【DTC Lookup Feature】Besides showing you the code’s definition while you are reading the diagnostic trouble codes, AL619 features comparably user-friendly DTC Lookup Function which enables you to retrieve the definitions of any error codes from the large database of AL619, saving you from the hassle of wasting time searching definition of every code via Google.
- iCarsoft i906 can do it all-reads and clears trouble codes for Volvo/Saab on full systems such as engine, transmission, ABS and airbag etc.
- Support OBD II/EOBD ten modes of operation full ecu diagnosis test modes include: CANBUS, ISO9141, KWP2000, J1850 etc.. Read & Clear DTCs Read live data stream
- OBD II function for all OBD II/EOBD compliant vehicles: I/M Readiness, Data Stream, Freeze Frame, O2 Sensor Test, Evap System Test, Turn off Check Engine Light (MIL)…
- Lifetime free update Upgrade via USB 2.0 one year warranty Support Multi-language
- VOL II can do it all-reads and clears trouble codes for Volvo Saab on all the systems such as engine, transmission, ABS and SRS etc. Read & Clear DTCs Read live data stream
- Oil light/service reset, Electronic Parking Brake (EPB) system maintenance, Steering Angle Sensor (SAS) Calibration, Diesel Particulate Filter (DPF) Regeneration Control System, Electronic Throttle Control system (ETC) reset
- OBD II function for all OBD II/EOBD compliant vehicles: I/M Readiness, Data Stream, Freeze Frame, O2 Sensor Test, Turn off Check Engine Light (MIL)…
- Lifetime free update Upgrade Via TF Card one year warranty Support Multi-language
- 🥇【MANUFACTURER-LEVEL DIAGNOSIS FITS FOR VOLVO】ANCEL VOD700 OBD2 scanner is specially designed for VOLVO vehicles. It can not only read and clear diagnostic fault codes of the main systems (Engine, Transmission, SRS, TPMS, ABS, SAS, ESP System, etc.), but also supports body, chassis, powertrain and all control modules. This helping you save money and time in maintenance or repair.
- ✅【ADVANCED MAINTENANCE FITS FOR VOLVO】As the most cost-effective OBDII scan tool fit for VOLVO vehicles in the market, ANCEL VOD700 diagnostic tool offers muti popular maintenance services fit for VOLVO vehicles, including Oil Reset, BMS Reset, ETC Reset, EPB Reset, TPMS Reset, ABS Bleeding and so on. VOD700 guides you through simple maintenance fixes, even if you are a beginner, you can perform basic maintenance on your own.
- 🚗【MUTIPLE OBDII MODE】For other Non-VOLVO vehicle models, VOD700 scan tool can only perform engine diagnostics, read & erase the trouble codes that can cause emission problems with your vehicle, turn off the MIL (check your car engine) and I/M readiness, read data stream, EVAP system test, vehicle identification Info (VIN, CIN, CVN) and so on, save you time and money. It supports 11 languages (English, German, Spanish, French, Italian, Russian, Portuguese, Finnish, Danish, Swedish, Norwegian).
- 👍【USER FRIENDLY DESIGN】Design-wise, the VOD700 is sleek and ergonomic. It is meant for beginners and professionals, because the data is usually displayed in a highly understandable way. The unique patented One-Click Readiness Key for quick State Emissions readiness check and drive cycle verification. Either way, you’ll find it easy to use with its nice display, responsive buttons, and a user-friendly menu.
- 👍【Auto VIN & Lifetime Free Upgrade】One-key Auto Vin scan function will recognize plug and read information, greatly saving time. VOD700 scan tool offers lifetime free software upgrades, new parameters, functions and the latest vehicle data are constantly updated via the USB2 port over the internet annually. Perform the upgrades on the device via WIFI, the scanner will always be up to date with the latest system within minutes.
- 🚕【Professional Diagnostic Tool】The NT510 Elite fit for Volvo is the latest and greatest version of after our NT510, NT520, and NT530 models. Packed with state-of-the-art AMP32 chips and featuring the newest software from October 2023, this upgrade delivers a massive boost in hardware-software compatibility and vehicle coverage. Our mission is to empower users with an even more powerful diagnostic experience, making it easier than ever to unleash the full potential of your vehicle.
- 🚗【Can Add more Vehicle Software】If you own two or more different brand vehicles, just need to pay $60-$80 to add one or more vehicle's software on the NT510 Elite scanner instead of buying more car scanner. 🚩Please notice the NT510 Elite diagnostic tool can be added 3 different models at most.
- 🚙【Full Bi-directional & Active Test】This OBD2 scanner diagnostic tool allows you to directly send commands from the scanner to your vehicle's ECU, enabling active tests specific to your car's components and parts which helps you confirm whether these parts are functioning properly and identify potential issues. Some of the components that can be tested include doors, windows, mirrors, locks, lights, headlamps, wipers, sunroofs, fuel injector pump, window/mirror/door lock/horn, cycle A/C clutch on/off, and turning A/C on or off ect.
- 🚕【Intuitive OE-Level All System Diagnosis 】 NT510 Elite code scanner for cars with One-Click VIN reading allows users diagnose all available electronic control modules. It offers car owners and technicians an easy and affordable solution to pinpoint trouble of the engine, abs, airbag, brake, transmission, audio, steering, a/c, headlamp, 4wd, windows, fuel system, esp and etc. Including read and clear fault codes, turn off the warning light, show the live data of various sensors in text and graph, retrieve frame freeze.
- 🚘【All Maintenance Service Reset】As the professional diagnostic tool fit for Volvo which offer Reset, Relearn, Match, Adaption, Calibration. Such as abs bleeding, battery registration, oil light reset, idle speed adjustment, traction/throttle body adjustment, A/C, CBS, activate alarm, crankshaft sensor relearn, epb, throttle body relearn, air suspension and etc. 🚩Note: Special Functions depends on the actual conditions of the vehicle, please confiem the VIN by QA or Email for compatibility check.
- iCarsoft VOL V2.0 can do it all-reads and clears trouble codes for Volvo/Saab on all the systems such as engine, transmission, ABS and airbag etc.
- Support OBD II/EOBD ten modes of operation full ecu diagnosis Update free The print data function allows you printing out diagnostic data recorded by the scan tool or customized test reports
- Oil light/service reset,Electronic Parking Brake (EPB) system maintenance,Steering Angle Sensor (SAS) Calibration,Diesel Particulate Filter (DPF) Regeneration Control System Battery Management System (BMS) reset
- NEW FUNCTIONS: ABS Bleeding and Injector coding (some vehicle models do not enjoy the two functions) ABS Bleeding, release the air to restore ABS Brake sensitivity, or relearn while ABS replaced. Injector coding, relearn the injector control parameter while the injector renewed or replaced
- 🚕【ABS, SRS Diagnosis Functions】The obd2 scanner diagnoses ABS/ SRS system codes on most 1996 and newer major vehicle models. Turns off Malfunction Indicator Light (MIL) and ABS/SRS warning lights, clears codes and resets monitors. Note: For double check, please contact us through MotorzoneUS@outlook.com, we will check the vehicle compatibility for you.
- 🚕【Full OBD2 Functions】 With ML619 OBD2 Scanner you can operate complete car diagnoses. Such as read/erase code, reade live date and freeze frame, I/M readiness status,O2 sensor test. The most direct and typical functions of this code scanner is to turn off the check engine light (MIL), which is completed via clearing the stored fault codes after the problems are solved
- 🚕【EXTENSIVE VEHICLE COVERAGE】ML619 supports more than 80 US, The scan tool works on most 1996 and newer vehicles (OBDII & CAN) including GM, Ford, Chrysler, Volvo, VW, BMW, Mercedes, Toyota, Honda, Nissan,Hyundai, Kia, Subaru, Mitsubishi, Peugeot, Citroen, Fiat, Renault, Land rover, Jaguar
- 🚕【Easy to Use】As an upgraded version of AL619, Autel ML619 troubleshooter code tips guide technicians to the root cause of trouble codes faster, saving diagnosis and repair time. The vehicle code reader retrieves generic (P0, P2, P3 and U0), manufacturer specific (P1, P3 and U1) codes and pending codes.
- 🚕【Free Life-time Updates & Print Data】Autel ML619 will comes with Free lifetime software update online and we offer 12 months warranty insurance. You can download the newest software anytime. The Print Data function allows printing out diagnostic data recorded by the scan tool or customized test reports.
- [OBD2 Scanner] The TOPDON OBD2 scanner performs all ENG/AT/SRS/ABS diagnostics with 4-in-1 graphic live data. 🚩It covers all OBD2 tests for 67 manufacturers and 10000+ model. It also features 5-second one-touch AutoVIN, 🚩a free one-touch lifetime upgrade through WiFi, library DTC, 12 languages, 🚩printable auto-generated report with email sharing, 🚩smooth Android 11.0, 32GB ROM, 🚩vivid 5-inch touchscreen, and up to 10 hours of battery life.
- [4 Car System Code Reader] The TOPDON OBD2 scanner accesses 4 systems: 🚩Engine/ABS/SRS/Transmission. It identifies the ECU version, pull DTCs with 4-in-1 graphic live data and DTC explanation to identify issues, erase DTCs to turn off the warning lights after repair (For cars made in 2005 and newer). In order to help you extend the lifespan of your vehicle while improving performance, this code reader also includes all obd2 test modes to solve the major concerns for all vehicles.
- [User-Oriented TOPDON OBD2 Scanner] With this scan tool's touchscreen and rubberized buttons, you may easily navigate through menus or process while following a logical path. With 32GB on-board memory, the scanner enables for the recording of several diagnostic reports, which can be shared via email and printed for review. Along with this, you can 🚩upgrade your software for free for lifetime with one-touch over Wi-Fi for that help update the features and expanding car coverage.
- [Multiple Functions] The Smart AutoVIN of this TOPDON OBD2 scanner keeps track of your manual selections for vehicle make, model, and year and directs you to the suitable diagnostics. 🚩Max 4 Live Data streams integrated for much easier data processing. Diagnostic feedback online with this diagnostic tool to help you get tough repair operations well-completed. Real-time car battery voltage monitoring identifies probable vehicle defects.
- [Wide Coverage] With its multilingual menu and 🚩coverage of 67 car brands and 10,000+ models spanning North America, Europe, and Asia (including Malaysia, India, and Iran), this car scanner is compatible with the majority of 1996 and newer OBDII compliant automobiles (EN, FR, ES, DE, IT, RU, PT, JP, KR). Before buying, make sure the OBD2 scanner is compatible with your vehicle. The package contains only a charging cable and not a power adapter.
Last update on 2024-04-08 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
Volvo Car USA LLC Quality Bulletin Bulletin Title
Recall R10259: Seatbelt Buckle, Model Year
2015-2024 XC90 Group
88 NO
R10259 Issuer (Dept.)
Product, Safety and
Compliance
Revisions Car Market
United States and Canada Issue Date
12/8/23 Page
Page 1 of 3 Status Date
12/8/23 A. RECALL R10259 DESCRIPTION
B. VEHICLES INVOLVED
C. PORT VEHICLES if applicable
D. PARTS INFORMATION/PARTS RETURN if applicable
E. QUALITY BULLETIN INSTRUCTIONS
F. OWNER NOTIFICATION
G. VEHICLES IN RETAILER INVENTORY
H. RETAILER RESPONSIBILITY
I. TECHNICIAN COMPETENCY REQUIREMENT
J. CAMPAIGN REIMBURSEMENT PROCEDURES & RETAILER ALLOWANCE A. RECALL R10259 DESCRIPTION
Volvo Cars USA LLC and Volvo Cars Canada LTD on behalf of the Volvo Car Corporation has decided to launch Recall R10259: Seatbelt Buckle on certain model year 2015-2024 XC90 vehicles. Volvo Car Investigations have determined that the second-row seatbelt buckles, and lower anchorages may have not been torqued to the correct specification. If the screw joint was not sufficiently tightened, the second-row seatbelt buckle may come loose in a crash, increasing the risk of injury. To remedy concerned vehicles, Volvo Cars will inspect the bolt torque on the second-row seatbelt buckle anchorage bolts ensuring all bolts are torqued according to specification. Volvo Cars centrally has not received any reports alleging injuries, fatalities, or crashes related to this condition. A total of 2,911 U.S. and 233 Canadian vehicles are eligible for this recall. WHAT SHOULD YOUR CUSTOMERS DO NOW?
We have no reports of incidents related to the issue; however, we encourage customers to
contact their retailer and have this repair completed as soon as possible. Quality Bulletin R10259 B. VEHICLES INVOLVED
NOTE: RETAILER MUST CONFIRM VEHICLE ELIGIBILITY PRIOR TO BEGINNING THE REPAIR FOR THIS RECALL. VEHICLES IN RETAILER INVENTORY MUST BE REPAIRED PRIOR TO SALE. Vehicle eligibility must be confirmed:
• Vehicle Inquiry – Warranty Vehicle Inquiry where the message “Recall R10259 Seatbelt Buckle” will appear for eligible vehicles, F4=History from the main Inquiry menu must be selected to confirm Recall R10259 has not been completed. Eligibility can also be confirmed in TIE. All vehicles must be checked for any incomplete recalls or service campaigns or service upgrades. All open Recall, Service Campaign or Service Action repairs must be completed. If you have any questions concerning this recall, send them to recall@volvocars.com. C. PORT VEHICLES
It is the retailer’s responsibility to check vehicle eligibility prior to delivery. D. PARTS / PARTS RETURN
No parts are required to be returned for this recall. E. QUALITY BULLETIN INSTRUCTIONS
For the recall to be performed, please follow the specific instructions found in the QBI. F. OWNER NOTIFICATION
An owner notification will be sent out in late-January that will notify the owner of this recall instructing them to contact their Volvo Retailer and request an appointment to have this repair completed.
G. VEHICLES IN RETAILER INVENTORY New Vehicles in Retailer Inventory
It is a violation of federal law for a retailer to deliver any new Volvo that is eligible for a recall. Retailers are advised to check all vehicles in inventory for recall eligibility and repair immediately. Violation of this requirement by a retailer could result in a civil penalty of up to
$26,315.00 per vehicle. Correct all vehicles in your new vehicle inventory before delivery. Used Vehicles in Retailer Inventory
VCUSA is ordering the stop-delivery of affected vehicles in VCUSA, auction and dealer inventory until the recalled item can be repaired. Stopping the delivery of affected used vehicles until the recall is complete is consistent with Volvo’s commitment to safety. Additionally, while Federal law does not prohibit the sale of used vehicles with open recalls, the sale of such cars could violate certain state laws and create liability on behalf of the retailer. Page 2 of 3 2023-12-08 2023-12-08 Page 3 of 3
Quality Bulletin R10259 What does this mean for customers?
The recall remedy is currently available, and customers can take delivery of their vehicle once the inspection has been performed per this recall. H. RETAILER RESPONSIBILITY
All vehicles qualifying for this recall must be repaired prior to a customer taking possession of the vehicle at new car delivery and or at any service appointment. I. TECHNICIAN COMPETENCY REQUIREMENT
The technician competency requirement for this campaign repair is Certified (G1). J. REIMBURSEMENT PROCEDURES & RETAILER ALLOWANCE
Recall R10259 claims should be submitted using the LONG FORM application only.
Claim Type: R10259
Cause Code: 02
CSC Code: XW
Main OP: 97838-2
Failed Part: (No Parts Involved) Operation Number Repair Description Qty Labor Time
97838-2 Safety belt acc. To QB 1 0.5
*Labor times provided are current at the time of release and are subject to change: e paid at the time in effect on the repair date.
**************************************************************************************************************
Volvo Car Customer Service QB Instruction VCC-528486-2
Title Safety belt buckle and safety belt tensioner Page 1 ( 14 )
Action Adjustment Operation number: Issue Date Reason
1 2023-12 First issue Affected vehicles
Model year Model 2016, 2017,
2018, 2019,
2020, 2021,
2022, 2023,
2024 XC90 (16-) QB Instruction VCC-528486-2 Page 2 ( 14 ) Color symbols Note! This colour chart displays (in colour print and electronic version) the importance of the different colours used in the images of the method steps.
1 . Used for focused component, the component with which you will do something.
2 . Used as extra colors when you need to show or differentiate additional parts.
3 . Used for attachments that are to be removed/installed. May be screws, clips, connectors, etc.
4 . Used when the component is not fully removed from the vehicle but only hung to the side.
5 . Used for standard tools and special tools. 6 . Used as background color for vehicle
components. Note! Orientation view QB Instruction VCC-528486-2 Page 3 ( 14 ) Disconnect the connector. Remove the screws.
Torque:
Rear seat, to body , 40 Nm Remove the screws.
Torque:
Rear seat, to body , 40 Nm QB Instruction VCC-528486-2 Page 4 ( 14 ) Hint: This step may require the aid of another technician.
Remove the marked part. Remove the screw. QB Instruction VCC-528486-2 Page 5 ( 14 ) Caution! Make sure that the component is positioned correctly. Install the screw.
Torque:
Seat belt bracket, to Seat , 40 Nm QB Instruction VCC-528486-2 Page 6 ( 14 ) Remove the screws. Remove the marked part. QB Instruction VCC-528486-2 Page 7 ( 14 ) Remove the screw. Caution! Make sure that the component is positioned correctly. QB Instruction VCC-528486-2 Page 8 ( 14 ) Install the screw.
Torque:
Buckle safety belt to seat , 40 Nm Note! Orientation view QB Instruction VCC-528486-2 Page 9 ( 14 ) Remove the screws. Remove the marked part. QB Instruction VCC-528486-2 Page 10 ( 14 ) Remove the screw. Caution! Make sure that the components are positioned correctly. QB Instruction VCC-528486-2 Page 11 ( 14 ) Install the screw.
Torque:
Buckle safety belt to seat , 40 Nm Note! Orientation view QB Instruction VCC-528486-2 Page 12 ( 14 ) Remove the screws. Remove the marked part. QB Instruction VCC-528486-2 Page 13 ( 14 ) Remove the screw. Caution! Make sure that the component is positioned correctly. QB Instruction VCC-528486-2 Page 14 ( 14 )
Install the screw.
Torque:
Buckle safety belt to seat , 40 Nm
Reinstall the removed parts in reverse order.
**************************************************************************************************************
Volvo Car US A LLC
Announcement Title
Recall R10259: Seatbelt Buckle
Issuer (Name, Dept.)
Quality, Product, Safety & Compliance
Audience (Retailer Job Role)
All U.S. and Canadian Volvo Retailers Issue Date
12/7/23 Version No.
1 Last Revision Date Page
Page 1 of 3
Dear Volvo Retailer Partner Volvo Cars USA LLC and Volvo Cars Canada LTD on behalf of the Volvo Car Corporation has decided to launch Recall R10259: Seatbelt Buckle on certain model year 2015-2024 XC90 vehicles. Volvo Car Investigations have determined that the second-row seatbelt buckles, and lower anchorages may have not been torqued to the correct specification. If the screw joint was not sufficiently tightened, the second-row seatbelt buckle may come loose in a crash, increasing the risk of injury. To remedy concerned vehicles, Volvo Cars will inspect the bolt torque on the second-row seatbelt buckle anchorage bolts ensuring all bolts are torqued according to specification. Volvo Cars centrally has not received any reports alleging injuries, fatalities, or crashes related to this condition. A total of 2,911 U.S. and 233 Canadian vehicles are eligible for this recall. All vehicles are currently marked in TIE and QW90 will follow early next week. NEW VEHICLES IN RETAILER INVENTORY
It is a violation of Federal law for a retailer to deliver any new Volvo that is eligible for a recall. Retailers are advised to check all vehicles in inventory for recall eligibility and repair immediately. Violation of this requirement by a retailer could result in a civil penalty of up to
$26,315.00 per violation. Correct all vehicles in your new vehicle inventory before delivery. USED VEHICLES IN RETAILER INVENTORY
Volvo Car USA is ordering the stop-delivery of affected vehicles in auction and retailer inventory until the recalled item can be repaired. Stopping the delivery of affected used vehicles until the recall is complete is consistent with Volvo’s commitment to safety. Additionally, while Federal law does not prohibit the sale of Volvo Car US A LLC
Announcement Title
Recall R10259: Seatbelt Buckle
Issuer (Name, Dept.)
Quality, Product, Safety & Compliance
Audience (Retailer Job Role)
All U.S. and Canadian Volvo Retailers Issue Date
12/7/23 Version No.
1 Last Revision Date Page
Page 2 of 3 used vehicles with open recalls, the sale of such cars could violate certain state laws and create liability on behalf of the retailer. What does this mean for customers?
We have no reports of incidents related to the issue; however, we encourage customers to contact their retailer and have this recall repair completed as soon as possible. Vehicle eligibility must be confirmed:
• Vehicle Inquiry – Warranty Vehicle Inquiry where the message “Recall R10259 Seatbelt Buckle” will appear for eligible vehicles. F4+History from the main Inquiry menu must be selected to confirm Recall R10259 has not been completed. Eligibility can also be confirmed in TIE.
• Recall R10259 eligible vehicles not yet delivered to customer must be corrected prior to delivery. All vehicles must be checked for any incomplete recalls, service campaigns or service upgrades. All open recalls, service campaigns or Service Action repairs must be completed. If you have any questions concerning this recall or your retailer’s affected vehicles, please send an e-mail with your retailer code to recall@volvocars.com. Owner Notification
An owner notification letter will be sent out in late-January that will notify the owner of this recall. Port Vehicles
It is the retailer’s responsibility to check vehicle eligibility prior to delivery. Parts / Parts Return
No parts are needed for this recall. Claim Submission
Claim submission instructions will be made available in the R10259 Quality Bulletin once available. Volvo Car US A LLC
Announcement Title
Recall R10259: Seatbelt Buckle
Issuer (Name, Dept.)
Quality, Product, Safety & Compliance
Audience (Retailer Job Role)
All U.S. and Canadian Volvo Retailers Issue Date
12/7/23 Version No.
1 Last Revision Date Page
Page 3 of 3
Retailer Responsibilities
Retailers must perform this recall campaign on eligible vehicles regardless of miles/kilometers or vehicle age. All work performed under this recall is free of charge to the owner. As the safety of our customers is our upmost priority, we are taking full responsibility to ensure the highest quality and safety standards for our cars. Your Cooperation in completing this important recall is greatly appreciated.
Sincerely
VCUSA Product, Safety, and Compliance
**************************************************************************************************************
OMB Control No.: 2127-0004
Part 573 Safety Recall Report 23V-827
The information contained in this report was submitted pursuant to 49 CFR §573
Manufacturer Name : Submission Date :
Volvo Car USA, LLC DEC 07, 2023 NHTSA Recall No. : 23V-827 Manufacturer Recall No. : R10259 Manufacturer Information :
Manufacturer Name : Volvo Car USA, LLC Address : 270 Three Point Drive
Ridgeville SC 29472
Company phone : 201-768-7300
Population :
Number of potentially involved : 2,911 Estimated percentage with defect : 5 %
Vehicle Information : Vehicle 1 : 2015-2024 Volvo XC90 Vehicle Type : LIGHT VEHICLES Body Style : SUV Power Train : GAS
Descriptive Information : This recall population is determined by the second-row seats that were pulled off the main production line at the supplier and rerouted to the rework repair line. The rework repair line was set up without torque angle monitoring in contrast to the main production line. The torque monitoring at the supplier’s rework repair line was updated the week of October 25, 2023, and vehicles after this date have the correct torque specification on the second-row seatbelt buckle attachment screws. This recall affects certain model year 2015-2024 XC90’s.
Production Dates : DEC 01, 2014 – SEP 23, 2023 VIN Range 1 : Begin : YV40621A7P1922431 End : YV4L12PVXP1934661 ✔ Not sequential Description of Defect :
Description of the Defect : The screw joints for the second-row seatbelt buckle attachment screw and the lower belt anchorage may have not been torqued to the correct specification.
FMVSS 1 : NR FMVSS 2 : NR
Description of the Safety Risk : If the attachment bolts were not sufficiently tightened, the second-row
seatbelt buckle and anchorage may come loose in a crash, increasing the risk of injury.
Description of the Cause : The supplier’s rework repair line for the second-row seat was set up without torque angle monitoring. Identification of Any Warning
that can Occur : Part 573 Safety Recall Report 23V-827 Page 2 Involved Components : Component Name 1 : Second Row Seatbelt buckle and anchor lower bolts. Component Description : Second Row Seatbelt buckle and anchor lower bolts. Component Part Number : NR Supplier Identification : Component Manufacturer
Name : Adient Sweden AB Address : Hamneviksvagen 101
Gothenburg Foreign States 41879
Country : Sweden Chronology :
Considered as a critical concern by CCMT 2023-11-29; Field Service Action decision confirmed by Volvo Car Corporation 2023-12-06; Condition detected by Factory; Number of vehicles reports with the condition, reported to Volvo Cars from the NSC 0; Total number of cars included in vehicle reports concerning this condition 0; Implementation date of Field Service Action 2023-12-07.
Extended Chronology: 2023-10-04 Volvo cars received the first factory notification indicating second row seat belt buckle was loose at the lower anchor. An investigation was initiated to review the factory symptom and a possible root cause. 2023-11-22 The investigation was escalated to the Critical Concern Action Process (CCAP). The issue was determined as potentially critical and the Critical Concern Management Team (CCMT) initiated a technical investigation to conclude customer symptom, risk assessment, testing, root cause etc together with the supplier. On 2023-11-29 the technical investigation was completed, the CCMT team took the decision to start preparation for a recall as it was judged that there is an increased risk towards motor vehicle safety. The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 23V-827
Page 3
The information contained in this report was submitted pursuant to 49 CFR §573
Description of Remedy :
Description of Remedy Program : To remedy concerned vehicles, Volvo Cars will inspect the bolt torque on
the second-row seatbelt buckle anchorage bolts ensuring all bolts are torqued according to specification. . If an out-of-pocket expense has been paid for prior to this repair being performed, prior to receiving this letter, customers may be eligible to receive reimbursement for the cost of obtaining a pre-notification remedy of the problem associated with this recall. For more information, please refer to Volvo Customer Care Center by phone at 1-800-458-1552, 24 hours a day, 7 days a week. You may also contact Volvo by going to https://volvo.custhelp/app/homeV3. How Remedy Component Differs from Recalled Component : Identify How/When Recall Condition was Corrected in Production : The torque monitoring on the re-work repair line at the supplier was updated the week of October 25, 2023, and vehicles after this date have the correct torque specification on the second-row seatbelt buckle attachment screws.
The torque monitoring on the re-work repair line at the supplier was updated the week of October 25, 2023.
Recall Schedule :
Description of Recall Schedule : Remedy Notices
Planned Dealer Notification Date : DEC 07, 2023 – DEC 07, 2023
Planned Owner Notification Date : JAN 29, 2024 – JAN 29, 2024
* NR – Not Reported
**************************************************************************************************************
**************************************************************************************************************
**************************************************************************************************************
**************************************************************************************************************
SEOCONTENT-END
