Volvo Car Customer Service QB Instruction VCC-523844-2 Title Accelerator pedal (with corrosion) Page 1 ( 14 ) Action APS Connector Kit Install Operation number: 97902-3 Issue Date Reason 1 2022-04 First issue Affected vehicles Model year Model Engine 2021, 2022 XC40 E400V6 Materials Materials Qty. Part No. Notes Splice 6.0 9130467 Electrical tape 0.1 Shop supplies Cable tie 3.0 983750 Thread locker normal 0.1 1161053 Shop supplies Accelerator pedal 1.0 32212368 APS connector kit 1.0 32301987 Special tools Description Part No. Crimping tool (included in 9512669) 951 2785 Hot-air gun 951 2777 Stripping tool (for wiring) 951 2620 Designation Part No. Pliers Equipment QB Instruction VCC-523844-2 Page 2 ( 14 ) Color symbols Note! This colour chart displays (in colour print and electronic version) the importance of the different colours used in the images of the method steps. 1. Used for focused component, the component with which you will do something. 2. Used as extra colors when you need to show or differentiate additional parts. 3. Used for attachments that are to be removed/installed. May be screws, clips, connectors, etc. 4. Used when the component is not fully removed from the vehicle but only hung to the side. 5. Used for standard tools and special tools. 6. Used as background color for vehicle components. Modification Install the marked component. QB Instruction VCC-523844-2 Page 3 ( 14 ) Press the components together. Special Tool: T9512785, Crimping tool (included in 9512669) Caution! Make sure that the surrounding components are protected from heat. Caution! Make sure that all openings are sealed to prevent capillary action (wicking). Special Tool: T9512777, Hot-air gun Heat the splice. While hot, crimp the end using pliers to seal it. QB Instruction VCC-523844-2 Page 4 ( 14 ) Use: APS connector kit, 32301987 QB Instruction VCC-523844-2 Page 5 ( 14 ) Note! Make certain the new repair terminals are paired to the correct wires. Note! Orientation view Note! Adapt the wiring length of the spare part to the wiring of the vehicle. Place the splices evenly distributed. Use: Splice , 9130467 QB Instruction VCC-523844-2 Page 6 ( 14 ) Special Tool: T9512620, Stripping tool (for wiring) QB Instruction VCC-523844-2 Page 7 ( 14 ) Special Tool: T9512785, Crimping tool (included in 9512669) QB Instruction VCC-523844-2 Page 8 ( 14 ) Caution! Make sure that the surrounding components are protected from heat. Special Tool: T9512777, Hot-air gun Caution! Ensure that the joint sleeve is properly shrunk around the wire. You should be able to see that glue has bonded as illustrated below. QB Instruction VCC-523844-2 Page 9 ( 14 ) Fold the cut wire back away from connector and secure to harness using tape. QB Instruction VCC-523844-2 Page 10 ( 14 ) Use: Electrical tape Background details are often deleted to make the picture clearer. Reinstall the removed part. Ensure that all clips engage QB Instruction VCC-523844-2 Page 11 ( 14 ) Install the cable. Ensure that all clips engage. Install the cable. Use: Cable tie, 983750 QB Instruction VCC-523844-2 Page 12 ( 14 ) Release the locks. Remove the marked part. Remove the nut. QB Instruction VCC-523844-2 Page 13 ( 14 ) Install component/components from the repair kit. Install the nut. Torque: M6 , 10 Nm Reinstall the removed part. Ensure that all clips engage. QB Instruction VCC-523844-2 Page 14 ( 14 ) Installation Note! Make sure that a new component is installed. To install, reverse the removal procedure. Install the marked component. Install the screw. Use: Thread locker normal , 1161053 Torque: M6 , 10 Nm Connect the connector.

**************************************************************************************************************

Service and Parts Business Parts Bulletin TITLE: Recall R10170 Accelerator Pedal Sensor Model / Year XC40 BEV MY2021-2022 GROUP: 27 CAT/NO: R10170 CAR MARKET: United States and Canada REVISIONS: ISSUE DATE: 2022-06-01 STATUS DATE: 2022-06-01 Page 1 of 1 “Right first time in Time” Produced and printed in the USA and available as an electronic document. © 2022 VOLVO CAR USA, LLC Reference Bulletins: QB R10170 Volvo Car USA LLC and Volvo Car Canada LTD on behalf of Volvo Car Group, have decided to launch Recall R10170 on certain model year 2021-2022 XC40 Battery Electric Vehicles (BEV). Volvo Cars Investigations have identified that water may enter the cable harness for the accelerator pedal. The water may cause corrosion in accelerator pedal internal circuits; this may cause the signals from the pedal to be corrupted increasing the risk of a crash. The corrective action is to inspect for corrosion in the Accelerator Pedal Sensor (APS) and connector terminals and change if fault detected. In all cars a capillary action breaking splice will be installed to prevent any risk of future water intrusion to the APS. If Diagnostic Trouble Code (DTC) P212200, P212300, P212700, P212800, P212036, P212037, P212038, P213800, or P060C92 are detected, replace the APS along with a new cable connector kit. A total of 5,351 U.S. and 459 Canadian vehicles are eligible for this recall. Part Number Description Qty 9130467 Splice 6 983750 Strip Clamp 3 32212368 Accelerator Pedal 1 32301987 Kit 1 32301988 Wire Harness 1 Shop Supply Electrical Tape 0.1 Shop Supply Thread Locker Normal 0.1

**************************************************************************************************************

Volvo Car Customer Service QB Instruction VCC-523313-1 Title Accelerator pedal (without corrosion) Page 1 ( 17 ) Action Connector inspection and ground wire installation Operation number: 97901-2 Issue Date Reason 1 2022-04 First issue Affected vehicles Model year Model Engine 2021, 2022 XC40 E400V6 Materials Qty. Part No. Notes Splice 1.0 9130467 Electrical tape 0.1 Shop supplies Cable tie 3.0 983750 Thread locker normal 0.1 1161053 Shop supplies Wiring harness 1.0 32301988 Materials Special tools Description Part No. Clip tool 981 4187 Crimping tool (included in 9512669) 951 2785 Hot-air gun 951 2777 Terminal removal tool (Color code: RED) 951 2632 Stripping tool (for wiring) 951 2620 Designation Part No. Pliers Equipment QB Instruction VCC-523313-1 Page 2 ( 17 ) Color symbols Note! This colour chart displays (in colour print and electronic version) the importance of the different colours used in the images of the method steps. 1. Used for focused component, the component with which you will do something. 2. Used as extra colors when you need to show or differentiate additional parts. 3. Used for attachments that are to be removed/installed. May be screws, clips, connectors, etc. 4. Used when the component is not fully removed from the vehicle but only hung to the side. 5. Used for standard tools and special tools. 6. Used as background color for vehicle components. Removal Set the vehicle to Inactive mode, described in user mode , refer to: General Information 3 – Electrical system 30 – General 300 – general Fold the carpet aside. QB Instruction VCC-523313-1 Page 3 ( 17 ) Remove the clip. Remove the marked part. Disconnect the connector. Remove the screw. Remove the marked part. QB Instruction VCC-523313-1 Page 4 ( 17 ) Note! Orientation view Note position of components. Caution! Observe caution when carrying out this step. Background details are often deleted to make the picture clearer. Remove the cable harness clips. Special Tool: T9814187, Clip tool Fold the cable harness aside. QB Instruction VCC-523313-1 Page 5 ( 17 ) Position / route the cable harness as illustrated. Remove the tape. QB Instruction VCC-523313-1 Page 6 ( 17 ) Cut the component according to the image. Remove the part carefully Remove the marked part. QB Instruction VCC-523313-1 Page 7 ( 17 ) Release the connector’s catch. Special Tool: T9512632, Terminal removal tool (Color code: RED) Pull the wiring through. Caution! Visually inspect the accelerator pedal connector for any signs of water intrusion and/or corrosion. QB Instruction VCC-523313-1 Page 8 ( 17 ) Check Caution! Visually inspect the wire for any signs of water intrusion and/or corrosion. NOTE! If water intrusion or corrosion is present in the previous two steps, follow QB instruction VCC-523844-2 – APS Connector Kit Install. Otherwise, continue with this instruction. QB Instruction VCC-523313-1 Page 9 ( 17 ) Modification Install the marked component. Use: Splice , 9130467 QB Instruction VCC-523313-1 Page 10 ( 17 ) Press the components together. Special Tool: T9512785, Crimping tool (included in 9512669) Caution! Make sure that the surrounding components are protected from heat. Caution! Make sure that all openings are sealed to prevent capillary action (wicking). Special Tool: T9512777, Hot-air gun Heat the splice. While hot, squeeze the end using pliers to seal it. QB Instruction VCC-523313-1 Page 11 ( 17 ) Use: wiring harness, 32301988 Install the cable. QB Instruction VCC-523313-1 Page 12 ( 17 ) Fold the cut wire back away from connector and secure to harness using tape. Use: Electrical tape. QB Instruction VCC-523313-1 Page 13 ( 17 ) Reinstall the removed part. Background details are often deleted to make the picture clearer. Reinstall the removed part. Ensure that all clips engage. QB Instruction VCC-523313-1 Page 14 ( 17 ) Install the cable. Ensure that all clips engage. Install the cable. Use: cable tie, 983750 QB Instruction VCC-523313-1 Page 15 ( 17 ) Release the locks. Remove the marked part. Remove the nut. QB Instruction VCC-523313-1 Page 16 ( 17 ) Install component from the repair kit. Install the nut. Torque: M6 , 10 Nm Reinstall the removed part. Ensure that all clips engage. QB Instruction VCC-523313-1 Page 17 ( 17 ) Installation Install the marked component. Install the screw. Use: Thread locker normal , 1161053 Torque: M6 , 10 Nm Connect the connector. To install, reverse the removal procedure.

**************************************************************************************************************

Service and Parts Business Quality Bulletin TITLE: Recall R10170: Accelerator Pedal Sensor, Model Year 2021-2022 XC40 BEV GROUP: 2711 CAT/NO: R10170 ISSUING DEPARTMENT: Product, Safety and Compliance CAR MARKET: United States and Canada REVISIONS: ISSUE DATE: 2022-05-31 STATUS DATE: 2022-05-31 Page 1 of 3 “Right first time in Time” Produced and printed in the USA and available as an electronic document. © 2022 VOLVO CAR USA, LLC A. RECALL R10170 DESCRIPTION B. VEHICLES INVOLVED C. PORT VEHICLES if applicable D. PARTS INFORMATION/PARTS RETURN if applicable E. QUALITY BULLETIN INSTRUCTIONS F. OWNER NOTIFICATION G. VEHICLES IN RETAILER INVENTORY H. RETAILER RESPONSIBILITY I. TECHNICIAN COMPETENCY REQUIREMENT J. CAMPAIGN REIMBURSEMENT PROCEDURES & RETAILER ALLOWANCE A. RECALL R10170 DESCRIPTION Volvo Car USA LLC and Volvo Car Canada LTD on behalf of Volvo Car Group, have decided to launch Recall R10170 on certain model year 2021-2022 XC40 Battery Electric Vehicles (BEV). Volvo Cars Investigations have identified that water may enter the cable harness for the accelerator pedal. The water may cause corrosion in accelerator pedal internal circuits; this may cause the signals from the pedal to be corrupted increasing the risk of a crash. The corrective action is to inspect for corrosion in the Accelerator Pedal Sensor (APS) and connector terminals and change if fault detected. In all cars a capillary action breaking splice will be installed to prevent any risk of future water intrusion to the APS. If Diagnostic Trouble Code (DTC) P212200, P212300, P212700, P212800, P212036, P212037, P212038, P213800, or P060C92 are detected, replace the APS along with a new cable connector kit. A total of 5,351 U.S. and 459 Canadian vehicles are eligible for this recall. Page 2 of 3 2022-05-31 Quality Bulletin R10170 WHAT SHOULD YOUR CUSTOMERS DO NOW? We have no reports of incidents related to the issue; however, we encourage customers to contact their retailer and have this repair completed as soon as possible. B. VEHICLES INVOLVED NOTE: RETAILER MUST CONFIRM VEHICLE ELIGIBILITY PRIOR TO BEGINNING THE REPAIR FOR THIS RECALL. Vehicle eligibility must be confirmed: • Vehicle Inquiry – Warranty Vehicle Inquiry where the message “Recall R10170 Accelerator Pedal Sensor” will appear for eligible vehicles, F4=History from the main Inquiry menu must be selected to confirm Recall R10170 has not been completed. Eligibility can also be confirmed in TIE. All vehicles must be checked for any incomplete recalls or service campaigns or service upgrades. All open Recall, Service Campaign or Service Action repairs must be completed. If you have any questions concerning this recall, send them to recall@volvocars.com. C. PORT VEHICLES There are no eligible vehicles in the ports. Vehicle eligibility must be confirmed as outlined in Step B. above. D. PARTS / PARTS RETURN Parts availability is very limited at this time, and retailers should only order if needed. Please refer to Parts Bulletin R10170 for part number information. E. QUALITY BULLETIN INSTRUCTIONS For the recall to be performed, please follow the specific instructions found in the QBI for vehicles with and without corrosion. F. OWNER NOTIFICATION An owner notification letter will be sent out sometime by mid-June that will notify the owner of this recall instructing them to contact their Volvo retailer and request an appointment to have this repair completed. G. VEHICLES IN RETAILER INVENTORY New Vehicles in Retailer Inventory It is a violation of US federal law for a retailer to deliver any new Volvo that is eligible for a recall. Retailers are advised to check all vehicles in inventory for recall eligibility and repair immediately. Violation of this requirement by a retailer could result in a civil penalty of up to$21,000 per vehicle. Correct all vehicles in your new vehicle inventory before delivery. 2022-05-31 Page 3 of 3 Quality Bulletin R10170 Used Vehicles in Retailer Inventory VCUSA is ordering the stop-delivery of affected vehicles in VCUSA, auction and dealer inventory until the recalled item can be repaired. Stopping the delivery of affected used vehicles until the recall is complete is consistent with Volvo’s commitment to safety. Additionally, while US Federal law does not prohibit the sale of used vehicles with open recalls, the sale of such cars could violate certain state laws and create liability on behalf of the retailer. What does this mean for customers? Customers will not be able to take delivery of affected vehicles until the recall has been completed. H. RETAILER RESPONSIBILITY All vehicles qualifying for this recall must be repaired prior to a customer taking possession of the vehicle. I. TECHNICIAN COMPETENCY REQUIREMENT The technician competency requirement for this campaign repair is: Level 3 – Certified Tech. J. REIMBURSEMENT PROCEDURES & RETIALER ALLOWNACE Recall R10170 claims should be submitted using the LONG FORM application only. Claim Type: R10170 Cause Code: 02 CSC Code: XW Main OP: 97901-2 Operation Number Repair Description Qty Models Labor Time 97902-3 APS Reconstruction of connector 1 XC40 BEV .4 acc: to QB R10170 97901-2 APS Control Contact acc: to 1 XC40 BEV .5 QB R10170 * Labor times provided are current at the time of release and are subject to change: Claims will be paid at the time in effect on the repair date. * 97901-2 is used on vehicles when no corrosion is detected only. * 97902-2 can be claimed along with 97901 when corrosion is detected.

**************************************************************************************************************

SAFETY RECALL NOTICE VOLVO CAR USA LLC PO Box 3757, Highland Park, Ml 48203-9984 IIIIIHI 1 PRESORT FIRST-CLASS U.S. POSTAGE PAID VOLVO CAR 13245 Main St. IMPORTANT SAFETY RECALL INFORMATION Any City, US 12345-6789 0 u .. s.0epa11rnont “‘- Issued inAcoordance with Federal Law ■NHTSA June 20, 2022 NHTSA RECALL 22V-288 IMPORTANT SAFETY RECALL THIS NOTICE APPLIES TO YOUR VEHICLE, VIN: Y Dear Volvo A. Owner, This notice is sent to you in accordance with the requirements of the National Traffic and Motor Vehicle Safety Act. Volvo Car USA LLC on behalf of Volvo Car Group, have decided that a defect, which relates to motor vehicle safety, exists in certain model year 2021-2022 XC40 Battery Electric Vehicles. The reason for Recall R10170: Water may enter the cable harness for the accelerator pedal. The water may cause corrosion in accelerator pedal internal circuits; this may cause the signals from the pedal to be corrupted increasing the risk of a crash. Recall action: Rl0170: The corrective action is to inspect for corrosion in the Accelerator Pedal Sensor (APS) and connector terminals and change if fault detected. In all cars a capillary action breaking splice will be installed to prevent any risk of future water intrusion to the APS, free of charge. Please contact your authorized Volvo retailer to schedule an appointment for the repair to be completed. This procedure will be completed at no cost and can take up to one hour to complete, however due to service scheduling your Volvo retailer may require your vehicle for a longer period. If you no longer own the vehicle described in this letter, please help us to update our records by sending us the updated owner information. Please refer to our contact information in this letter. Please contact: If you have any questions, please contact your Volvo retailer. If your retailer is unable to answer your questions, please contact Volvo Customer Care Center: 1800 Volvo Place Mahwah, NJ 07430 Or by phone at 1-800-458-1552, 24 hours a day, 7 days a week. You may also contact us by going to http://volvocars.us/support. We have advised the National Highway Traffic Safety Administration (NHTSA) that we are conducting this recall. If you are unable to have this procedure performed without charge, and within a reasonable period of time, you may contact the NHTSA Administrator at: National Highway Traffic Safety Administration 1200 New Jersey Avenue, SE. Washington, DC 20590 Or you can call the toll-free Vehicle Safety Hotline at 1-888-327-4236 (TTY: l-800-424-9153). You may also go to their website, http://www.safercar.gov. Federal law requires that any vehicle lessor receiving this recall notice must forward a copy of this notice to the lessee within ten days. To learn more about Volvo safety recalls, scan the QR Code below or visit us at: https ://www. vo lvocars. com/us/ own/additional-choices/recall-information Your safety and continued satisfaction with your Volvo and the Volvo organization are very important to us. We apologize for any inconvenience this may cause, and we are working to have this important Service completed as quickly as possible. Sincerely, …I Vincent D ‘Auria Senior Manager Product, Safety and Compliance – Regulatory & Compliance 1-800-458-1552

**************************************************************************************************************

Vincent D’Auria Senior Manager Product, Safety & Compliance – Regulatory & Compliance April 28, 2022 Subject: Recall R10170 TO: All U.S. and Canadian Volvo Retailers NEW VEHICLES IN RETAILER INVENTORY It is a violation of federal law for a retailer to deliver any new Volvo that is eligible for a recall. Retailers are advised to check all vehicles in inventory for recall eligibility and repair immediately. Violation of this requirement by a retailer could result in a civil penalty of up to $22,723 per violation. Correct all vehicles in your new vehicle inventory before delivery. USED VEHICLES IN RETAILER INVENTORY Volvo Car USA is ordering the stop-delivery of affected vehicles in auction and retailer inventory until the recalled item can be repaired. Stopping the delivery of affected used vehicles until the recall is complete is consistent with Volvo’s commitment to safety. Additionally, while Federal law does not prohibit the sale of used vehicles with open recalls, the sale of such cars could violate certain state laws and create liability on behalf of the retailer. What does this mean for customers? Customers will not be able to take delivery of affected vehicles until the recall has been completed. When will this be resolved? Volvo Car USA LLC and Volvo Car Canada LTD on behalf of Volvo Car Group, have decided to launch Recall R10170 on certain model year 2021-2022 XC40 BEV vehicles. Volvo Cars Investigations have identified that Water may enter the cable harness with capillary action and enter the accelerator pedal. The water may cause corrosion in accelerator pedal internal circuits; this may cause the signals from the pedal to be corrupted. Depending on which signal that gets corrupted the faults may differ, vehicles have a built-in safety logic when receiving faulty signals which reduces the acceleration. The vehicle is still controllable, and the customer can always stop the vehicle with the brake pedal. The corrective action is to inspect for corrosion in the Accelerator Pedal Sensor (APS) and connector terminal and change if fault detected. In all cars capillary breaking splice will be installed to stop any risk of water intrusion towards APS. Volvo Cars centrally has not received any reports alleging injuries, fatalities, or crashes related to this condition. Volvo Car USA LLC Page 1 of 2 270 Three Point Drive Ridgeville, SC 29472 Telephone +1-201-768-7300 volvocars.us A total of 5,351 U.S. and 459 Canadian vehicles are eligible for this recall. Vehicle eligibility must be confirmed: • Vehicle Inquiry – Warranty Vehicle Inquiry where the message “Recall R10170 Accelerator Pedal Sensor” will appear for eligible vehicles, F4+History from the main Inquiry menu must be selected to confirm Recall R10170 has not been completed. Eligibility can also be confirmed in TIE. • Recall R10170 eligible vehicles not yet delivered to end customers must be corrected prior to delivery. All vehicles must be checked for any incomplete recalls or service campaigns or service upgrades. All open Recall, Service Campaigns or Service Action repairs must be completed. If you have any questions concerning this recall or your retailers’ affected vehicles, please send an e-mail with your retailer code to recall@volvocars.com. OWNER NOTIFICATION An owner notification letter will be sent out in late June that will notify the owner of this recall. PARTS / PARTS RETURN Please review Parts Bulletin R10170 once available. CLAIM SUBMISSION Claim submission instructions will be made available in the Quality Bulletin. RETAILER RESPONSIBILITIES Retailers must perform this recall campaign on eligible vehicles regardless of miles/kilometers or vehicle age. All work performed under this recall is free of charge to the owner. As the safety of our customers is our upmost priority, we are taking full responsibility to ensure the highest quality and safety standards for our cars. If you have questions about this recall or any other field service action, please contact me or any member of the Product Safety and Compliance office. Your cooperation in completing this important recall is greatly appreciated. Drive Safely, Vincent D’Auria Senior Manager Product, Safety and Compliance – Regulatory & Compliance 201-647-0004 vincent.dauria@volvocars.com Page 2 of 2

**************************************************************************************************************

Vincent D’Auria Senior Manager Product, Safety & Compliance – Regulatory & Compliance May 13, 2022 Subject: Recall R10170 TO: All U.S. and Canadian Volvo Retailers NEW VEHICLES IN RETAILER INVENTORY It is a violation of federal law for a retailer to deliver any new Volvo that is eligible for a recall. Retailers are advised to check all vehicles in inventory for recall eligibility and repair immediately. Violation of this requirement by a retailer could result in a civil penalty of up to $22,723 per violation. Correct all vehicles in your new vehicle inventory before delivery. USED VEHICLES IN RETAILER INVENTORY Volvo Car USA is ordering the stop-delivery of affected vehicles in auction and retailer inventory until the recalled item can be repaired. Stopping the delivery of affected used vehicles until the recall is complete is consistent with Volvo’s commitment to safety. Additionally, while Federal law does not prohibit the sale of used vehicles with open recalls, the sale of such cars could violate certain state laws and create liability on behalf of the retailer. What does this mean for customers? Customers will not be able to take delivery of affected vehicles until the recall has been completed. When will this be resolved? Volvo Car USA LLC and Volvo Car Canada LTD on behalf of Volvo Car Group, have decided to launch Recall R10170 on certain model year 2021-2022 XC40 Battery Electric Vehicles (BEV). Volvo Cars Investigations have identified that water may enter the cable harness for the accelerator pedal. The water may cause corrosion in accelerator pedal internal circuits; this may cause the signals from the pedal to be corrupted increasing the risk of a crash. The corrective action is to inspect for corrosion in the Accelerator Pedal Sensor (APS) and connector terminals and change if fault detected. In all cars a capillary breaking splice will be installed to prevent any risk of future water intrusion to the APS. Volvo Cars centrally has not received any reports alleging injuries, fatalities, or crashes related to this condition. Volvo Car USA LLC Page 1 of 2 270 Three Point Drive Ridgeville, SC 29472 Telephone +1-201-768-7300 volvocars.us A total of 5,351 U.S. and 459 Canadian vehicles are eligible for this recall. Vehicle eligibility must be confirmed: • Vehicle Inquiry – Warranty Vehicle Inquiry where the message “Recall R10170 Accelerator Pedal Sensor” will appear for eligible vehicles, F4+History from the main Inquiry menu must be selected to confirm Recall R10170 has not been completed. Eligibility can also be confirmed in TIE. • Recall R10170 eligible vehicles not yet delivered to end customers must be corrected prior to delivery. All vehicles must be checked for any incomplete recalls or service campaigns or service upgrades. All open Recall, Service Campaigns or Service Action repairs must be completed. If you have any questions concerning this recall or your retailers’ affected vehicles, please send an e-mail with your retailer code to recall@volvocars.com. OWNER NOTIFICATION An owner notification letter will be sent out in late June that will notify the owner of this recall. PARTS / PARTS RETURN Parts are expected to be arriving in the U.S. in late May and we will release the retailer package with instructions around the same time. Please review Parts Bulletin R10170 once available. As the safety of our customers is our upmost priority, we are taking full responsibility to ensure the highest quality and safety standards for our cars. If you have any questions about this recall or any other field service action, please send an e-mail with your retailer code to recall@volvocars.com. CLAIM SUBMISSION Claim submission instructions will be made available in the Quality Bulletin. RETAILER RESPONSIBILITIES Retailers must perform this recall campaign on eligible vehicles regardless of miles/kilometers or vehicle age. All work performed under this recall is free of charge to the owner. As the safety of our customers is our upmost priority, we are taking full responsibility to ensure the highest quality and safety standards for our cars. If you have questions about this recall or any other field service action, please contact me or any member of the Product Safety and Compliance office. Your cooperation in completing this important recall is greatly appreciated. Drive Safely, Vincent D’Auria Senior Manager Product, Safety and Compliance – Regulatory & Compliance 201-647-0004 vincent.dauria@volvocars.com Page 2 of 2

**************************************************************************************************************

OMB Control No.: 2127-0004 Part 573 Safety Recall Report 22V-288 The information contained in this report was submitted pursuant to 49 CFR §573 Manufacturer Name : Volvo Car USA, LLC Submission Date : APR 28, 2022 NHTSA Recall No. : 22V-288 Manufacturer Recall No. : R10170 Manufacturer Information : Manufacturer Name : Volvo Car USA, LLC Address : 270 Three Point Drive Ridgeville SC 29472 Company phone : 201-768-7300 Population : Number of potentially involved : 5,351 Estimated percentage with defect : 1 % Vehicle Information : Vehicle 1 : 2021-2022 Volvo XC40 BEV Vehicle Type : LIGHT VEHICLES Body Style : 4-DOOR Power Train : HYBRID ELECTRIC Descriptive Information : Vehicles produced between 9-08-2020 and 8-13-2021 had an older style harness. There was a change in the cable harness supplier and the last vehicle produced with the older style harness was produced on 8-13-2021. The make and model affected by this is the Volvo XC40 BEV MY 2021-2022. Production Dates : SEP 08, 2020 – AUG 13, 2021 VIN Range 1 : Begin : YV4ED3UR9M2439208 End : YV1XZEDVEN2663838 Not sequential Description of Defect : Description of the Defect : Water may enter the cable harness with capillary action and enter the accelerator pedal. The water may cause corrosion in accelerator pedal internal circuits; this may cause the signals from the pedal to be corrupted. FMVSS 1 : NR FMVSS 2 : NR Description of the Safety Risk : Customer may experience unintended acceleration or no acceleration, loss of drive or no start, increasing the risk of a crash. Description of the Cause : Cable harness from supplier may not be waterproof. Water intrusion from potentially damaged cable harness may corrode circuit accelerator pedal sensor (APS) causing unintended APS signals. Identification of Any Warning that can Occur : Depending on which signal that gets corrupted the faults may differ, vehicles have a built-in safety logic when receiving faulty signals which reduces the acceleration. The vehicle is still controllable, and the customer can always stop the vehicle with the brake pedal. Part 573 Safety Recall Report 22V-288 Page 2 The information contained in this report was submitted pursuant to 49 CFR §573 Involved Components : Component Name 1 : Left wheelhouse harness Component Description : Accelerator Pedal Harness Component Part Number : NR Supplier Identification : Component Manufacturer Name : Leoni Wiring Systems France Address : 5 Avenue Newton Montigny Le Bretonneux Foreign States F-78180 Country : France Chronology : In the first quarter of 2022 Volvo Cars starts to receive reports indicating different issues with accelerator pedal behaviour: no acceleration or bad response and jerky behaviour. Volvo Cars R&D initiated an investigation on possible issue and further discussion and analysis with cable harness supplier. The issue was presented to Critical Concern Management Team (CCMT) April 6, 2022. CCMT ordered a start of technical investigation including risk assessment. The technical investigation was completed April 20 and presented to CCMT. CCMT ordered start preparation for a safety recall. The recall preparation was completed April 27 and is scheduled to launch April 28. Description of Remedy : Description of Remedy Program : To remedy the concerned vehicles Volvo Cars will inspect for corrosion in APS and connector terminal and change if fault detected. In all cars capillary breaking splice will be installed to stop any risk of water intrusion towards APS. All vehicles repaired at no cost to the customer under Volvo Warranty. How Remedy Component Differs from Recalled Component : Adding water-breaking cable splice, to cancel capillary water intrusion towards accelerator pedal. Identify How/When Recall Condition was Corrected in Production : Change of cable harness supplier. Last Vehicle produced at Volvo site, 2021-08-13. Part 573 Safety Recall Report 22V-288 Page 3 The information contained in this report was submitted pursuant to 49 CFR §573 Recall Schedule : Description of Recall Schedule : Remedy Notices Planned Dealer Notification Date : APR 28, 2022 – APR 28, 2022 Planned Owner Notification Date : JUN 20, 2022 – JUN 20, 2022 * NR – Not Reported

**************************************************************************************************************

OMB Control No.: 2127-0004 Part 573 Safety Recall Report 22V-288 The information contained in this report was submitted pursuant to 49 CFR §573 Manufacturer Name : Volvo Car USA, LLC Submission Date : JUN 08, 2022 NHTSA Recall No. : 22V-288 Manufacturer Recall No. : R10170 Manufacturer Information : Manufacturer Name : Volvo Car USA, LLC Address : 270 Three Point Drive Ridgeville SC 29472 Company phone : 201-768-7300 Population : Number of potentially involved : 5,351 Estimated percentage with defect : 1 % Vehicle Information : Vehicle 1 : 2021-2022 Volvo XC40 BEV Vehicle Type : LIGHT VEHICLES Body Style : 4-DOOR Power Train : HYBRID ELECTRIC Descriptive Information : Vehicles produced between 9-08-2020 and 8-13-2021 had an older style harness. There was a change in the cable harness supplier and the last vehicle produced with the older style harness was produced on 8-13-2021. The make and model affected by this is the Volvo XC40 BEV MY 2021-2022. Production Dates : SEP 08, 2020 – AUG 13, 2021 VIN Range 1 : Begin : YV4ED3UR9M2439208 End : YV1XZEDVEN2663838 Not sequential Description of Defect : Description of the Defect : Water may enter the cable harness with capillary action and enter the accelerator pedal. The water may cause corrosion in accelerator pedal internal circuits; this may cause the signals from the pedal to be corrupted. FMVSS 1 : NR FMVSS 2 : NR Description of the Safety Risk : Customer may experience unintended acceleration or no acceleration, loss of drive or no start, increasing the risk of a crash. Description of the Cause : Cable harness from supplier may not be waterproof. Water intrusion from potentially damaged cable harness may corrode circuit accelerator pedal sensor (APS) causing unintended APS signals. Identification of Any Warning that can Occur : Depending on which signal that gets corrupted the faults may differ, vehicles have a built-in safety logic when receiving faulty signals which reduces the acceleration. The vehicle is still controllable, and the customer can always stop the vehicle with the brake pedal. Part 573 Safety Recall Report 22V-288 Page 2 The information contained in this report was submitted pursuant to 49 CFR §573 Involved Components : Component Name 1 : Left wheelhouse harness Component Description : Accelerator Pedal Harness Component Part Number : NR Supplier Identification : Component Manufacturer Name : Leoni Wiring Systems France Address : 5 Avenue Newton Montigny Le Bretonneux Foreign States F-78180 Country : France Chronology : Considered as a critical concern by Critical Concern Management Team 04.20.2022; Field Service Action decision confirmed by Volvo Car Corporation 04.27.2022; Implementation date of Field Service Action 04.28.2022; Condition detected by Market; Number of vehicle reports with the condition reported to Volvo Cars from National Sales Company 28; Total number of cars included in Vehicle Reports concerning this condition 28. In the first quarter of 2022 Volvo Cars starts to receive reports indicating different issues with accelerator pedal behaviour: no acceleration or bad response and jerky behaviour. Volvo Cars R&D initiated an investigation on possible issue and further discussion and analysis with cable harness supplier. The issue was presented to Critical Concern Management Team (CCMT) April 6, 2022. CCMT ordered a start of technical investigation including risk assessment. The technical investigation was completed April 20 and presented to CCMT. CCMT ordered start preparation for a safety recall. The recall preparation was completed April 27 and is scheduled to launch April 28. Description of Remedy : Description of Remedy Program : To remedy the concerned vehicles Volvo Cars will inspect for corrosion in APS and connector terminal and change if fault detected. In all cars capillary breaking splice will be installed to stop any risk of water intrusion towards APS. All vehicles repaired at no cost to the customer under Volvo Warranty. Part 573 Safety Recall Report 22V-288 Page 3 The information contained in this report was submitted pursuant to 49 CFR §573 How Remedy Component Differs from Recalled Component : Adding water-breaking cable splice, to cancel capillary water intrusion towards accelerator pedal. Identify How/When Recall Condition was Corrected in Production : Change of cable harness supplier. Last Vehicle produced at Volvo site, 2021-08-13. Recall Schedule : Description of Recall Schedule : Remedy Notices Planned Dealer Notification Date : APR 28, 2022 – APR 28, 2022 Planned Owner Notification Date : JUN 20, 2022 – JUN 20, 2022 * NR – Not Reported
