NHTSA ID Number: 10161791
Manufacturer Communication Number: ST-232-2019-02-2
Summary
This is a Special Tool Bulletin: Newsletter 83 Mandatory Tools
53 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| VOLVO | S60 | 2011-2018 |
| VOLVO | S60CC | 2016-2018 |
| VOLVO | S60I | 2016-2018 |
| VOLVO | S80 | 2007-2016 |
| VOLVO | V60 | 2015-2018 |
| VOLVO | V60CC | 2015-2018 |
| VOLVO | V70 | 2008-2010 |
| VOLVO | XC60 | 2011-2019 |
| VOLVO | XC70 | 2008-2016 |
SEOCONTENT-START
VOLVO CAR
SERVICE AND PARTS BUSINESS
Special Tools Bulletin
TITLE:
Newsletter 83: Mandatory Tools
NO:
232
ISSUE DATE: 2019-02-21 CAR MARKET:
United States and
Canada Page 1 of 2
STATUS DATE: 2019-02-21
Service
Personnel:
Read and
initial
SERVICE
MANAGER
PARTS
MANAGER
WORKSHOP
FOREMAN
SERVICE TECHNICIANS
Produced in the USA and available as an electronic document. Hard copy documents are printed in USA on recycled paper containing
a minimum of 50% wastepaper and 10% post-consumer waste.
© 2019 VOLVO CAR USA, LLC
“Right first time in Time”
All tools have been classified as required, and will be allocated and billed to all U.S. and Canadian
retailers by Volvo.
All tool allocations and tool orders are being handled by the Volvo Parts Operations and the Volvo
Parts Distribution Centers.
Overview of content:
Art No. Description Standard
9997698 Adapter C1
9997701 Drift C1
9997698 Adapter
For dismantling and mounting of bushing link arm.
Used with Hydraulic Cylinder 9512923.
Works together with 9997467B, 9997468B and
9997470B.
Tool standard C1
Tool group 65.0
Tool bulletin 414
Model S80(07-), V70(08-), XC70(08-),
XC60, S60, S60 (11-) V60
Tool board 65
Page 2 of 2 2019-02-21
Special Tools Bulletin 232
9997701 Drift
Used for mounting of sealing ring on converter.
Tool standard C1
Tool group 43.0
Tool bulletin 414
Model TF-71SC Transmission
Tool board 43
C1
33300322
9997698 Adapter
9997701 Drift
SEOCONTENT-END
NO: 232
STATUS DATE: 2019-02-21
